l Safety certification: TUV Rheinland certified, in line with SPQ2 BGV D8/D8+/C1 standard
l Max. speed: 42m/min
l Working load: 0.25T, 0.32T, 0.5T, 0.8T, 1T, 2T
l Load cell: Optional shackle type or internal integrated
l Safety protection: 4-point limit switch
l Safety feedback: Motor thermal protection switch, brake feedback switch
l Brake: 2*DC
l Chain: In accordance with EN818-7-DAT standard
l Encoder: Three positions for installing encoders
l Work level: ISO:M5
l Protection level: IP66 protection level, suitable for outdoor
l Modular Design: Flexible and scalable structure allows for easy expansion, integration, and maintenance.
l Operating Speed: Standard speed of 0.6 m/s ensures efficient and smooth stage equipment movement.
l Track Options: Available in both single-track and DST truss configurations to suit different structural setups and load requirements.
l Support curved tracks: With a minimum radius of 3m, allowing flexible layout designs for complex stage setups.
l High Load Capacity: Support loads of up to 2 tons, making it suitable for heavy-duty applications.
l Accessories: Equipped with optional slave trolleys and wire trolleys for power and signal cable management.
l Customizable Solutions: Configurations can be tailored to site-specific needs, offering practical solutions for various operational scenarios.
l Local controls: 8x3-positiontravel direction switch
l Emergency stop: Meet SIL3 standards andincludes dual power supply contactors with a self healing feature for enhancedsafety
l Position protection: Support connection to incremental or absolute encoders for position detection andsoftware protection
l Limit protection: Support limit switch input and display
l Load protection: Connect to load cells to achieve overload and underload protection
l Group safety protection: During simultaneous operation, an alarm from a single device can trigger a quickshutdown of other devices
l Maximum number of cascades: 12 units
l Maximum support for control loops: 96 units
l Commissioning free: Suitablefor installation and commissioning in various performance venues
l Load cell: Shackle form，support both wired and wireless configurations
l Safety factor: High safety factor, provide 10x safety protection
l Measuring range: 1T~5T, 150%F.S overload capacity
l Connections: Composite power supply, communication cables, single point and Daisy chain
l Controller: 1 controller controls up to 100 load sensors
l Monitoring interface: Multi-region monitoring page and various monitoring interfaces
l Data recording: Real time load monitor and real-time running data recording
l Safety protection: Protection of alarm, underload, and overload
l Certified reliability: With third-party testing reports, ensure accuracy and compliance with industry standards
l Safety certification: TUV Rheinland certified SIL3 safety level
l Control object: Chain hoist, lifting platform, track car, screen, etc.
l Motor: Servo motor, 3-phase asynchronous motor
l Redundancy: Ring network, multi-console
l External trigger: DMX, LTC time code
l Direct nodes: 1 control system to 128, and 1 console to 1024
l Safety protection: Over range, limit, under&overload, speed&position deviation
l Control mode: Speed closed loop, position closed loop
l Encoder: 2 encoders: incremental & absolute
l Compact design: Innovative, non-welded aluminum round-tube frame structure supports 360° installation
l Dual Brakes: Redundant braking system for enhanced safety.
l Dual Encoders: Precise position feedback for accurate motion control.
l Dual Load Cells: Real-time load monitoring and overload protection.
l EN17206 Compliance: Design meets European safety standards for stage machinery.
l Removable Wheel Structure: Suitable for both mobile stage performances and permanent venue installations.
l Flexible Configurations: Support two- or four-winch setups for 2D/3D flying performances
